Cast Iron Conical Assay Mold, 24 depression (6×4)

Description

24 depression assay pouring mold in a 6×4 pattern.

The Heat Resistant (HR) molds are made of a cast iron alloy with Copper (Cu), Manganese (Mn), Chromium (Cr), and Nickel (Ni) for increased heat resistance. HR molds are designed to provide higher durability, while remaining cost effective. These HR molds are made to withstand an additional 300 degrees (f) higher than standard cast iron molds.

Pricing is per each (1) HR mold.
Each cavity is approximately 2.75" in diameter x 1.5" deep
3 inch (76mm) cone spacing

Overall dimensions: 12-3/4" x 20-1/4"

Cast iron conical molds for pouring the fire assay melt. Separates the slag and lead button.

Can also be used as a refining mold to pour a cone shaped ingot.
