Cress C-163210 Furnace with Watlow PM6 controller w/HLC & Exhaust Blower

Description

Cress C-163210 Furnace with Watlow PM6E controller, High Limit Controller and Exhaust Blower

USES: This furnace is designed for general use in the shop, laboratory or factory that require temperatures from 300°F to 2250°F. Their use includes heat treating metals, ashing processes, assaying and all types of testing.
TEMPERATURE CONTROLS: Auto tuning microprocessor-based Watlow PM6 controller. Solid-state zero voltage switching of power to elements improves temperature control. Other Controllers available.
ELEMENTS: Cress winds precision (digitally controlled element winder) high-temperature iron-aluminum alloy wire into elements and mounts them on the side walls in alumina plates.
GENERAL CONSTRUCTION: Case constructed from heavy gauge sheet steel and finished in gray hammer tone enamel. The easily operated, counter-balanced door is always away from the operator. All walls and the door constructed of the finest quality -insulating firebrick backed by up with 1900°F block insulation (there is no asbestos).
SAFETY SWITCH: These models come equipped with a door safety switch. When door opens, elements disconnect from the power source. Solid-state zero voltage switching of power to elements.

Venturi Exhaust Vent Kit
This furnace includes the factory installed exhaust blower.
Motor details:
Volts: 220v/60hz
0.53 Amps, 3000 RPM
Approximate volume: 70-80 CFM

Inside dimensions: 16″ wide x 32″ deep x 10″ high
Outside dimensions: 29″ wide x 45″ deep x 30″ high
Shipping Weight: 455 lbs
Shipping Dimensions: 57″ x 40″ x 41″

Volts: 230
Kilowatts: 10
Insulation Thickness: 4″
Max F Temp: 2250
